Key Features
1. Premium Cold Light Source
Equipped with imported German OSRAM LED chips, energy-saving with a service life of over 80,000 hours. The temperature rise around the surgeon’s head is less than 1℃.It emits no infrared or ultraviolet radiation, avoiding wound overheating and tissue damage caused by traditional halogen lamps, and accelerates wound healing without radiation pollution.The color temperature remains stable with no light decay, delivering soft, anti-glare light similar to natural sunlight.Dual-spectrum design with R9 red light and R11 green light: R9 enhances color rendering to clearly show wound tissues and tiny blood vessels for high-precision surgery; R11 optimizes ambient lighting to relieve visual fatigue during long operations.
2. Excellent Shadowless Performance
Modular ultra-thin three-petal lamp head with multi-point light source ensures even illuminance and flexible spot adjustment, maintaining perfect shadowless effect even when partially blocked.Adopts diamond-cut lens structure to reduce light loss and improve light utilization. It diffuses harsh direct light, effectively lowering glare for comfortable lighting.
3. Superior Deep Illumination
Computer-aided modular optical design creates an effective lighting depth over 1200mm, with maximum central illuminance up to 160,000Lux. The adjustable color temperature of 3700K~5000K restores authentic tissue color to meet various surgical lighting requirements.
4. Intelligent Control System
Microcomputer digital control system with LCD touch screen for brightness and color temperature adjustment. Built-in three working modes: general lighting mode, endoscopic mode and dim light mode.Automatic memory function saves preferred settings for direct use after restart.Independent multi-circuit design ensures a single faulty LED will not affect the overall operation of the lamp.
5. Flexible Balanced Suspension Arm
Fitted with imported balance spring components, the arm is lightweight, easy to operate and precisely positioned with a wide adjustment range.Equipped with fatigue correction and positioning fine-tuning device for convenient calibration after long-term use.
6. Mobile Base with Lockable Casters
Four-point supporting base equipped with high-grade silent universal casters. Each caster has an independent brake, enabling flexible movement, stable positioning and quiet operation.
7. Laminar Flow Optimized Lamp Head
Germany-designed ultra-thin three-petal lamp head with streamlined appearance, maximum thickness ≤9cm for excellent laminar airflow. Each petal is fitted with an integrated handle for easy operation.The lamp housing is made of ABS material. The detachable central handle can withstand 134℃ high-pressure autoclave sterilization.
Technical Specifications
| Parameter | Specification |
|---|
| Lamp Head Type | Three-petal |
| Adjustable Illuminance | 20,000–160,000Lux |
| LED Quantity | 48pcs |
| Light Source | Imported OSRAM LED |
| LED Lifespan | ≥80,000hrs |
| Adjustable Color Temperature | 3700K~5000K |
| Color Rendering Index (Ra) | ≥96 |
| Focus Depth | 50–180cm |
| Spot Diameter | 120–300mm Adjustable |
| Brightness Regulation | 1%~100% Stepless Adjustable |
| Power Consumption | 48W |
| Operator Head Temp Rise | ＜1℃ |
| Input Voltage | AC100-240V 50/60Hz |
| Installation Type | Mobile Floor-standing |
| Warranty | 2 Years |
