1. Working power supply: AC220V, 50Hz;
2, double cross arm range (radius) : 835mm and 835mm (can be configured according to the requirements of the hospital)
Transverse arm thickness > 10mm
3, horizontal rotation Angle: 0 ~ 340°, the transverse arm and the terminal box can be respectively or simultaneously horizontal rotation;
4, net load ≥180kg;
5, instrument platform: 3 layers (height adjustable) 560mm×550mm, silicon gel Angle protection anti-collision design;
6, the gas interface German standard 2 oxygen 2 suction 2 air (can be configured according to hospital requirements) :
a, interface color and shape is different, with anti-error function;
b. More than 20,000 times of insertion and removal;
c, the use of secondary seal, with three states (on, off, pull), with gas maintenance;
7, power sockets: 8, 220V, 10A; 1 network interface; Ground terminal: 2;
8, one drawer, stainless steel adjustable infusion rod frame 1;
9, the power supply and air source interface on both sides of the tower body, fully realize the separation of electricity and gas, to ensure the safe use of equipment;
10, surface treatment using electrostatic spraying;
11. The main material is made of high-strength aluminum alloy profiles;
12, ceiling installation, stable and firm.
