1. Working power supply: AC220V, 50Hz;
2, the movement range of the transverse arm (radius) : 700-1100mm (can be configured according to the requirements of the hospital)
Transverse arm thickness: > 10mm
3, the terminal box can rotate Angle: 0 ~ 340°
4, net load ≥220kg;
5, instrument platform: 2 layers (height adjustable) 660mm*450mm, silicon gel Angle protection anti-collision design;
6, gas interface configuration (national standard 2 oxygen 2 suction 2 air or according to the requirements of the hospital) :
a, interface color and shape is different, with anti-error function;
b. More than 20,000 times of insertion and removal;
c, the use of secondary seal, with three states (on, off, pull), with gas maintenance;
7, power socket: 10, 220V, 10A; 1 network interface; Ground terminal: 2;
8. 1 drawer; Stainless steel adjustable infusion rod frame 1;
9. The power interface is at the back of the tower body, and the air source is distributed on both sides of the tower body, fully realizing the separation of electricity and gas to ensure the safe use of the equipment.
10, surface treatment using electrostatic spraying;
11. The main material is made of high-strength aluminum alloy profiles;
12, ceiling installation, stable and firm.
13. Special display rack for endoscope room and internal mirror rack can be selected.
14, the cross arm is equipped with a rotating arm, the use of new alloy materials made of octagonal type, rotating arm rotation Angle 360° unlimited rotation. The balance system uses imported arm spring components, lightweight structure, easy to handle, precise positioning, and can provide the maximum adjustment range. Can hang 17~32 inches of display, built-in equipment required wire installation display, can adjust the position and Angle of the display according to the field situation.
