1、 Core Lighting Performance
Luminous flux regulation system
Adopting intelligent PWM dimming technology, supporting 10% -100% stepless brightness adjustment
The color temperature remains constant at 4500K ± 5%, ensuring true color rendering in the surgical field of view
The maximum central illumination can reach 140000 lux (at a distance of 800mm from the lamp panel)
Optical System Design
Patent composite lens group, eliminating multiple shadows
Adjustable range of spot diameter: Φ 150mm - Φ 350mm
Depth illumination uniformity>90% (0-1200mm working distance)
2、 Structural design features
Mechanical suspension system
Five axis universal joint structure, supporting 360 ° rotation
Maximum extension radius of 2.8 meters
Damping balance system achieves precise positioning with one hand
Thermal management system
Pure copper heat pipe+active cooling of turbofan
Continuous working for 12 hours, temperature rise ＜ 15 ℃
IP54 protection level dustproof and waterproof
3、 Intelligent control system
Touch screen control panel:
6 preset surgical lighting modes
Real time display of parameters such as illuminance and temperature
Optional features:
Foot switch control
Integration of surgical field camera system
Hospital HIS system integration
4、 Clinical application advantages
Compliant with YY 9706.250-2023 Medical Device Standard
Average service life>50000 hours
Support quick replacement of LED modules (<3 minutes)
