| Head & Foot Interchangeable Function | None |
| Base Shell Material | 304 Stainless Steel |
| Wheels with Brake | 4 hydraulic jacks |
| Bed Side Frame Material | 304 Stainless Steel |
| Emergency Brake Release Valve | Optional |
| Brake | Electric hydraulic |
| Total Length | 2070 |
| Width | 540 |
| Max. Load Capacity | 520 KG |
| Safe Working Load | 275 KG |
| Net Weight (Bed Only) | 285 kg |
| Main Material | 304 Stainless Steel |
| Height Adjustment (without padding) | 540–1040 |
| Trendelenburg / Reverse Trendelenburg | 30° |
| Lateral Tilt | 20° |
| Longitudinal Sliding Function | 320 mm (350 mm optional) |
| Mattress / Pad | 80 mm |
| Handheld Controller | Yes |
| Controller Display (2.4-inch) | LCD optional |
| Column Controller | Yes |
| Wireless Controller (2.4-inch) | Optional |
| Wireless Controller (3.5-inch) | Optional |
| Foot Switch | Optional |
| Auto Standby | Yes, 70-second automatic shutdown |
| Flexion / Reflexion / Button | 220° / 110° |
| Zero Position Button (One-key Reset Function) | Yes |
| Interchangeable Head & Leg Plates | Yes |
| Position Memory Function (5 positions) | Optional |
| Side Rails (Rail Dimensions) | US standard 28.5×9.5 |
| X-Ray | Optional |
| Maximum Radiolucent Length | 1350 mm |
| Head Plate Control Mode | Gear |
| Head Plate Up / Down | Gear adjustment type: +60° to -90° |
| Back Plate Control Mode | Electric hydraulic |
| Back Plate | 1 section |
| Back Plate Up / Down Angle | +80° to -40° |
| Kidney Bridge Control Mode | Manual |
| Kidney Bridge Up / Down Height | 120 mm |
| Component Plug-in Connection Mode | Screw locking |
| Leg Plate Control Mode | Manual gas spring adjustment |
| Leg Plate Up / Down | 30° / -90° / 180° |
| Power Supply | AC 110–220V |
| Battery | 24V 15AH |
| Safety Level | One-key reset |
| Reverse V Position | Yes |
| Double-layer Tabletop | Optional |
| Caster Diameter | 2×75 mm + 2×50 mm |
| Caster Rotation & Directional Lock | 4 universal casters |
| Secondary Mechanical Drive Function (mechanical operation available in case of electric control failure) | Optional |
| Packing Dimensions | 140×73×115 (cm) |
| Weight | Approx. 350 kg (including accessories) |
