| Head-to-toe Interchange Function | Yes |
| Base Housing Material | 304 stainless steel |
| Wheel Brake System | Four hydraulic jack columns |
| Table Top Frame Material | 304 stainless steel |
| 5th Caster Brake Valve |
|
| Central Brake | Electric hydraulic |
| Mobility |
|
| Overall Length | 2090 |
| Overall Width | 540 |
| Maximum Load Capacity | 520KG |
| Safe Working Load (SWL) | 265KG |
| Net Weight |
|
| Main Body Material | 304 stainless steel |
| Design Type |
|
| Height Adjustment (without Mattress) | 540-1040 |
| Trendelenburg / Reverse Trendelenburg | 30° |
| Lateral Tilt | 20° |
| Longitudinal Translation | 320（Optional 350mm） |
| Mattress / Pad | 80mm |
| Handheld Controller | Yes |
| Controller Display (2.4-inch) | LCD Option Selection |
| Column-mounted Controller | Yes |
| Wireless Controller (2.4-inch) | Optional |
| Wireless Controller (3.5-inch) | Optional |
| Foot Switch | Optional |
| Auto Standby | Yes Automatic shutdown in 70 seconds |
| Flexion / Reflexion Buttons | 220°/110° |
| Zero-Position Reset Button | Yes |
| Interchangeable Head/Leg Plate | Yes |
| Position Memory Function (5 Presets) | Standard countertop angle (height and sliding options available) |
| Side Rail (Rail Size) | Majestic 28.5*9.5 |
| X-ray Compatibility | Optional |
| Maximum Radiolucent Area | 1590mm |
| Head Plate Control Type | Gears and air springs |
| Head Plate Dimensions |
|
| Head Plate Up/Down Angle | Gear adjustment model + 60° - 90° |
| Back Plate Control Type | Electric hydraulic |
| Back Plate | 1 section |
| Back Plate Up/Down Angle | +80° - 40° |
| Kidney Bridge Control Type | NO |
| Kidney Bridge Height Adjustment | NO |
| Leg Plate Control Type | Manual air spring adjustment |
| Leg Plate Up/Down Angle | 30°/-90°/180° |
| Power Supply | AC110-220V |
| Backup Battery | 24V15AH |
| Safety Class | One-click reset |
| Reverse V Position / Forward V Position | Yes |
| Dual-layer Table Top | Optional |
| Caster Diameter | 4*100mm |
| Caster Rotation & Directional Lock | 4 universal casters |
| Manual Emergency Drive | Optional |
| Packing Dimensions | 140*73*115(cm) |
| Gross Weight | 350kg(including Accessories） |
