Advantages:

1.Maintenance free,oil-less pump,and high flow rate with less po- llution.

2.Large-diameter storage bottle,stopper with sealingring,easyto open,fasten down and clean.

3.Overflow protection device preventsliquid from entering into the inner pipe and pump.

4. Transparent non-toxicPVC hoses,easy for observation

5.Air filter protects pump from being polluted

6.Hand switch and foot switch installed in parallel,can be selectec at will.

7.Work stably and durably, low noise,long service life

Specifcation parameter

1.MaxVacuum:≥0.09MPa(680mmHg)

2.Adjustable vacuum range:0.02~0.09MPa(150~680mmHg

3.Flow rate:≥40L/min

4.Noise:≤60dB(A)

5.Storage bottles: 2500mlx2(glass)(the two or one of them

can be changed to 2L or 3L PC bottle)

6.Input: 250VA

7.Power supply:AC220V 50Hz

8.Dimension:360mmx320mmx830mm

9.Package Dimension:465mmx425mmx935mm10.GW/NW.:23.5kg/20kg
