High-accuracy infusion control with compatibility for most IV sets.
Reminders for infusion start and residual time display.
Adjustable air bubble and pressure alarm thresholds with volume control.
IV-set clamp prevents accidental liquid flow.
A.B.S-ANTI BOLUS system prevents high-dose injection risks.
Automatic flow shut-off during alarms (excluding critical alarms).
Compact aluminum enclosures ensure durability.
USB port for software updates by technical personnel.
Versatile bracket for flexible mounting on infusion poles.
Calibration support for user-provided IV sets to ensure accuracy.
Specification：
| Item | Specification |
|---|
| Display | 2.8 inch LCD, button control |
| Infusion Modes | Rate, Time, Drop, BodyWeight, Drug Library |
| Infusion Principle | Fingertip Peristaltic Pump |
| IV Set Compatibility | Open System, compatible with PVC/TPE IV sets (3.8mm-4.2mm) |
| Flow Rate Range | 0.1-1200 ml/h, step by 0.1 ml/h |
| Purge/Bolus Rate | 1-1200 ml/h, default 800 ml/h |
| Single Bolus Volume | 1.0-10 ml, default 3 ml |
| Time Preset Range | 00:01~99:59 (Hour: Min) |
| Volume Range | 1~9999 ml |
| Drop Range | 1-400 d/min, step by 1 drop |
| Accuracy | ±5% |
| Alarms | Air in line, Occlusion, Door Open, VTBl Completion, Low Battery, Battery Exhausted, Low Temperature, Motor Malfunction, AC Disconnection, IV set dislocation, MPU Error, Battery Charging, Circuit Malfunction |
| KVO | 1-5 ml/h, default 1 ml/h, programmable by user |
| Occlusion Pressure | Low 40KPa±20KPa; Middle 60KPa±20KPa; High 100KPa±20KPa |
| Internal Battery | Lithium battery, 10.8/2200mAh, more than 4 hours backup |
| Power Supply | 30VA; AC100V-240V 50HZ/60HZ |
| Classification | Class II, type CF, IPX4 |
| Optional Function | Ambulance DC12V, WIFI, Language customization |
