| Display | 2.8 inch LCD, button control |
| Channel | Single (SPA-112) or Double (SPA-122) |
| Stackable | Only for Single Channel SPA-112 |
| Infusion Modes | Rate, Time, Drug Library |
| Syringe Sizes | 5, 10, 20, 30, 50ml; automatic detection |
| Safety Design | Double CPU for higher reliability & accuracy |
| Accuracy | ±2% |
| Time Preset Range | 00:01~99:59 (Hour: Min) |
| Volume Range | 0.1-9999 ml |
| Flow Rate Step | 0.1 ml/h |
| Flow Rate Range | Varies with syringe size |
| Purge/Bolus Rate | Varies with syringe size |
| Alarms | Auto Self-Test, Syringe Dislocation, Occlusion, Near End, Syringe Empty, VTBl Completion, Low Battery, Battery Exhausted, Motor Malfunction, Incorrect Syringe Specification, Circuit Malfunction, Parameters Over Limitation, AC Disconnection, AC connection |
| KVO | Adjustable range from 0.1 ml/h to 5.0 ml/h |
| Occlusion Pressure | Low 40KPa±20KPa; Middle 60KPa±20KPa; High 100KPa±20KPa |
| Internal Battery | Lithium battery, 10.8/2200mAh, 4-8 hours backup |
| Power Supply | 30VA/45VA; AC100V-240V 50HZ/60HZ |
| Classification | Class II, type CF, IPX4 |
| Optional Function | Ambulance DC12V, WIFI, Language customization |
| Package Material | carton box |
| Dimension | 350x280x210mm |
| GW/NW | 3.5/3kg |
