Features:
●This table is suitable for general, gynecology, obstetric,proctology, urology and
orthopaedic operation.
●Radiolucent table top and longitudinal moving 350mm function are very convenient
for X-ray examination and C-arm photograph on different parts of body.
●Ultra-low position design, suitable for neurosurgery.
●It adopts electro hydraulic system, smooth and silent operation.
●The height ,back section, trendelenburg,lateral and moving 300mm adjustments are
all controlled by electro hydraulic.
●The head is manual adjustment and leg section air spring adjustment.
●Made of full premium 304 stainless steel. Mobile stainless steel base on castors
with central brake.
●It also has one key 0 position, one key flex and reflex, emergency stop switch,
power indicator, storage battery indicator function.
●Double controller system, one is hand remote controller, the other is on column.
Specification:
| Demensions: | 2100*550mm |
| Height Adjustment(electro hydraulic)： | 550-1050mm |
| Trendelenburg(electro hydraulic)： | ±30° |
| Lateral Tilt(electro hydraulic)： | ±20° |
| Back Section (electro hydraulic)： | +85°/-40° |
| Head Board (manual)： | +45°/-90° |
| Leg Board (manual)： | +30°/-90° |
| Table Top Longitudinal Moving(electro hydraulic): | 350mm |
| Build-in Kidney Elevator(manual)： | 0-120mm |
| Flex/Reflex: | 220°/110° |
| 0 position |
| Sotrage battery |
| Double Controller |
