1.Overall Dimensions: (2350 × 540) ± 10 mm
2.Table Height (without mattress): Minimum Height: (650 ± 20) mm Maximum Height: (1010 ± 20) mm
3.Height Adjustment Range: (360 ± 20) mm (Electric)
4.Longitudinal Sliding Range: (260 ± 20) mm (Electric)
5.Trendelenburg / Reverse Trendelenburg: 22° ± 2° (Electric)
6.Lateral Tilt: Left: 25° ± 2° (Electric) Right: 23° ± 2° (Electric)
7.Backrest Adjustment: Up: 60° ± 2° (Electric) Down: 20° ± 2° (Electric)
8.Leg Plate Adjustment: Up: 35° ± 5° (Manual) Down: 90° ± 5° (Manual)
Abduction: 90° ± 5° (Manual)
9.One-Touch Reset Function: Supported
10.Tabletop Material: Made of radiolucent material, capable of horizontal movement to provide precise positioning space for the C-arm during X-ray imaging.
11.Backplate: Made of a single 1.15 m ultra-long carbon fiber board without metal obstruction, making it more suitable for orthopedic surgeries.
12.Mattress: Made of high-density, soft integral sponge, naturally contoured with memory recovery function to reduce localized pressure.
13.Table and Accessories: Made of high-quality nickel-chromium stainless steel, ensuring durability, long-term rust resistance, and enhanced accessory reliability.
14.Leg Plate Mechanism: Equipped with a quick-release button and abduction quick lock, allowing medical staff to quickly replace the orthopedic traction frame.
15.Braking System: Four-corner fixed electric braking system ensures the operating table remains level and stable.
