Features:
☆ Bolt structure
☆ High quality stainless steel material
☆ Microcomputer automatic control, arbitrary set of sterilization parameters
☆ Digital display and touch buttons
☆ Standard test interface
☆ The container with automatic protection function: over temperature protection; over pressure protection self discharge; low water level protection, anti dry burning
☆ With stainless steel bucket or basket
☆ Buzzer reminder after sterilization, automatic stop.
☆ Automatic cooling air, sterilization end automatic exhaust steam
Technical Parameter:
| Technical parameter | DGLS-35B | DGLS-50B | DGLS-75B | DGLS-100B | DGLS-120B | DGLS-150B |
|---|
| Volume | 35L | 50L | 75L | 100L | 120L | 150L |
| Power | 2.5kw | 3.5kw | 4.5kw | 4.5kw | 4.5kw | 6.0kw |
| Voltage | AC 220V, 50HZ | AC 220V, 50HZ | AC 220V, 50HZ | AC 220V, 50HZ | AC 220V, 50HZ | AC 220V, 50HZ |
| Design pressure | 0.25MPa | 0.25MPa | 0.25MPa | 0.25MPa | 0.25MPa | 0.25MPa |
| Design temperature | 139℃ | 139℃ | 139℃ | 139℃ | 139℃ | 139℃ |
| Rated working pressure | 0.22MPa | 0.22MPa | 0.22MPa | 0.22MPa | 0.22MPa | 0.22MPa |
| Rated working temperature | 134℃ | 134℃ | 134℃ | 134℃ | 134℃ | 134℃ |
| Sterilization temperature setting range | 116℃~134℃ | 116℃~134℃ | 116℃~134℃ | 116℃~134℃ | 116℃~134℃ | 116℃~134℃ |
| Sterilization time setting range | 4 ~ 120 min | 4 ~ 120 min | 4 ~ 120 min | 4 ~ 120 min | 4 ~ 120 min | 4 ~ 120 min |
| Drying time setting range | 0 ~ 240 min | 0 ~ 240 min | 0 ~ 240 min | 0 ~ 240 min | 0 ~ 240 min | 0 ~ 240 min |
| Chamber dimension | Φ300×500mm | Φ350×525mm | Φ400×625mm | Φ450×650mm | Φ450×760mm | Φ500×780mm |
| Bucket dimension | Φ280×400mm | Φ330×460mm | Φ380×560mm | Φ420×540mm | Φ420×660mm | Φ470×720mm |
| Optional basket dimension | — | Φ320×240×2pcs | Φ360×280×2pcs | Φ410×300×2pcs | Φ410×350×2pcs | Φ460×350×2pcs |
| Outer dimension (L×W×H) | 400×400×860mm | 480×480×960mm | 525×525×1060mm | 555×555×1080mm | 555×599×1200mm | 605×649×1210mm |
| Packing size (L×W×H) | 550×500×1030mm | 580×630×1100mm | 630×680×1190mm | 690×650×1230mm | 690×650×1330mm | 750×700×1370mm |
| Gross / Net weight | 58/41kg | 75/53kg | 82/61kg | 103/78kg | 108/82kg | 116/90kg |
