Features:
☆ Hand wheel translation and quick opening structure
☆ Three times pre-vacuum
☆ High quality stainless steel material
☆ Microcomputer automatic control, arbitrary setting sterilization parameters
☆ Safety interlocking device
☆ LED touch screen display
☆ Standard test interface
☆ Self-expanding seal
☆ With drying function
☆ With stainless steel bucket or basket
☆ With automatic protection function: over temperature protection; over pressure self discharge protection ; low water level protection; anti dry burning.
☆ Automatic water
☆ External steam Generator
☆ Buzzer reminder after sterilization, automatic stop.
☆ Automatic discharge of cold air, automatic steam exhaust after sterilization
☆ Internal printer
Technical Parameter:
| Technical parameter | DGL-35M | DGL-50M | DGL-75M | DGL-100M |
|---|
| Volume | 35L | 50L | 75L | 100L |
| Power | 3.5kw | 3.5kw | 4.5kw | 4.5kw |
| Voltage | AC 220V, 50HZ | AC 220V, 50HZ | AC 220V, 50HZ | AC 220V, 50HZ |
| Design pressure | 0.25MPa | 0.25MPa | 0.25MPa | 0.25MPa |
| Design temperature | 139℃ | 139℃ | 139℃ | 139℃ |
| Rated working pressure | 0.22MPa | 0.22MPa | 0.22MPa | 0.22MPa |
| Rated working temperature | 134℃ | 134℃ | 134℃ | 134℃ |
| Sterilization temperature setting range | 116℃-134℃ | 116℃-134℃ | 116℃-134℃ | 116℃-134℃ |
| Sterilization time setting range | 4 ~ 120 min | 4 ~ 120 min | 4 ~ 120 min | 4 ~ 120 min |
| Drying time setting range | 0 ~ 240 min | 0 ~ 240 min | 0 ~ 240 min | 0 ~ 240 min |
| Chamber dimension | Φ350×400mm | Φ400×505mm | Φ400×655mm | Φ450×650mm |
| Bucket dimension | Φ330×320mm | Φ380×430mm | Φ380×560mm | Φ420×540mm |
| Optional basket dimension | Φ320×350mm | Φ360×280×1pc | Φ360×280×2pcs | Φ410×300×2pcs |
| Outer dimension (L×W×H) | 698×498×940mm | 630×500×1180mm | 725×525×1170mm | 760×560×1260mm |
| Packing size (L×W×H) | 790×610×1130mm | 800×600×1230mm | 840×610×1310mm | 870×650×1380mm |
| Gross / Net weight | 130/115kg | 138/118kg | 150/124kg | 159/132kg |
