Features:
☆ Hand wheel translation and quick opening structure
☆ High quality stainless steel material☆ With drying function☆ Microcomputer automatic control, arbitrary setting sterilization parameters☆ Safety interlocking device☆ Digital display and Touch buttons☆ Standard test interface☆ Self-expanding seal☆ With automatic protection function: over temperature protection; over pressure self discharge protection ; low water level protection; anti dry burning.☆ With stainless steel bucket or basket☆ Buzzer reminder after sterilization, automatic stop.☆ Automatic discharge of cold air, automatic steam exhaust after sterilization, Internal steam cycle.*Optional external printer
*Optional automatic water
Technical Parameter:
| Technical parameter | DGL-35X | DGL-50X | DGL-75X | DGL-100X |
|---|
| Volume | 35L | 50L | 75L | 100L |
| Power | 3.5kw | 3.5kw | 4.5kw | 4.5kw |
| Voltage | AC 220V, 50HZ | AC 220V, 50HZ | AC 220V, 50HZ | AC 220V, 50HZ |
| Design pressure | 0.25MPa | 0.25MPa | 0.25MPa | 0.25MPa |
| Design temperature | 139℃ | 139℃ | 139℃ | 139℃ |
| Rated working pressure | 0.22MPa | 0.22MPa | 0.22MPa | 0.22MPa |
| Rated working temperature | 134℃ | 134℃ | 134℃ | 134℃ |
| Sterilization temperature setting range | 116℃-134℃ | 116℃-134℃ | 116℃-134℃ | 116℃-134℃ |
| Sterilization time setting range | 4 ~ 120 min | 4 ~ 120 min | 4 ~ 120 min | 4 ~ 120 min |
| Drying time setting range | 0 ~ 240 min | 0 ~ 240 min | 0 ~ 240 min | 0 ~ 240 min |
| Chamber dimension | Φ350×400mm | Φ350×525mm | Φ400×625mm | Φ450×650mm |
| Bucket dimension | Φ330×320mm | Φ330×460mm | Φ380×560mm | Φ420×540mm |
| Optional basket dimension | Φ320×350mm | Φ320×240×2pcs | Φ360×280×2pcs | Φ410×300×2pcs |
| Outer dimension (L×W×H) | 698×498×940mm | 630×500×1180mm | 725×525×1170mm | 788×588×1255mm |
| Packing size (L×W×H) | 790×610×1130mm | 800×600×1230mm | 840×610×1310mm | 870×650×1380mm |
| Gross / Net weight | 125/110kg | 130/112kg | 145/114kg | 156/129kg |
