Features:
☆ Hand wheel translation and quick opening structure
☆ High quality stainless steel material
☆ Microcomputer automatic control, arbitrary setting sterilization parameters.
☆ Safety interlocking device
☆ Digital display and Touch buttons
☆ Standard test interface
☆ Self-expanding seal
☆ With drying function
☆ With automatic protection function:over temperature protection; over pressure protection; low water level protection; anti dry burning.
☆ With stainless steel bucket or basket
☆ Buzzer reminder after sterilization, automatic stop.
☆ Automatic discharge of cold air,automatic steam exhaust after sterilization.
*Optional external printer
*Optional automatic water
Technical Parameter:
| Technical parameter | DGL-35G | DGL-50G | DGL-75G | DGL-100G |
|---|
| Volume | 35L | 50L | 75L | 100L |
| Power | 3.5kw | 3.5kw | 4.5kw | 4.5kw |
| Voltage | AC 220V, 50HZ | AC 220V, 50HZ | AC 220V, 50HZ | AC 220V, 50HZ |
| Design pressure | 0.25MPa | 0.25MPa | 0.25MPa | 0.25MPa |
| Design temperature | 139℃ | 139℃ | 139℃ | 139℃ |
| Rated working pressure | 0.22MPa | 0.22MPa | 0.22MPa | 0.22MPa |
| Rated working temperature | 134℃ | 134℃ | 134℃ | 134℃ |
| Sterilization temperature setting range | 116℃-134℃ | 116℃-134℃ | 116℃-134℃ | 116℃-134℃ |
| Sterilization time setting range | 4 ~ 120 min | 4 ~ 120 min | 4 ~ 120 min | 4 ~ 120 min |
| Drying time setting range | 0 ~ 240 min | 0 ~ 240 min | 0 ~ 240 min | 0 ~ 240 min |
| Chamber dimension | Φ350×400mm | Φ350×525mm | Φ400×625mm | Φ450×650mm |
| Bucket dimension | Φ330×320mm | Φ330×460mm | Φ380×560mm | Φ420×540mm |
| Optional basket dimension | Φ320×350mm | Φ320×240×2pcs | Φ360×280×2pcs | Φ410×300×2pcs |
| Outer dimension (L×W×H) | 480×480×1000mm | 480×480×1120mm | 525×525×1190mm | 550×550×1250mm |
| Packing size (L×W×H) | 580×630×1130mm | 580×630×1230mm | 630×680×1290mm | 690×650×1410mm |
| Gross / Net weight | 79/58kg | 106/80kg | 120/90kg | 133/106kg |
