Specifications:
| Overall bed dimensions: | 1940*660*530/870mm |
| Bed top dimensions: | 1940*580mm, minimum width: 530mm |
| Overall width: | 660mm |
| Height adjustment range: | 340mm; height adjustment: 550–930mm |
| Backrest adjustment: | 0–75° |
Features:
Backrest adjustment system:
Backrest and knee rest controlled by gas springs, stepless adjustment 0–75°.
Height adjustment system: linkage mechanism driven by manual regulator.
Body: Steel body with powder coating.
Bed top: PP resin material, one-piece injection molding, three-section bed board.
Frame: Overall frame made of steel / part aluminum.
Castors: Double-wheel with central locking.
Four castors with diameter ≥150mm. Central locking pedals installed at four corners.
Independent 5th wheel steering system:
Equipped with independent central 5th wheel system. Control pedals on both sides.
Side rails:
Made of PP resin, can be fixed horizontally with safety devices.
Equipped with angle indicator to show backrest angle.
Groove design to prevent infusion tube slipping.
Transport mattress:
Waterproof surface treatment, removable and washable cover.
Infusion pole sockets:
One socket at each corner. Infusion pole can be fixed.
Standard infusion pole with storage holes.
The stretcher adopts international advanced central brake system, stable and reliable.
Bed top is split structure, upper part supported by imported gas springs, easy and convenient to operate.
Packing:
Packaging dimensions: 2030*800*630mm
Gross weight: 100KG
