Specifications:
Overall dimensions: L3650×W640×H640/970 mm
Features:
Guide Rails
The connecting stretcher rails are die-cast from international high-strength A380.2 aluminum alloy, ensuring smoother and more reliable movement of the bed platform.
Body Structure
The stretcher body is welded with high-quality carbon steel, treated with rust removal and electrostatic resin powder coating.
Bed Top & Side Rails
Bed top is injection-molded in one piece with imported ABS engineering plastic.
Backrest supported by imported gas springs for easy and convenient operation.
Four silent pulleys installed at the bottom of the bed platform.
Lifting side rails made of imported ABS engineering plastic by one-piece injection molding on both sides.
Height Adjustment
Both single stretchers are height adjustable to the same level for smooth sliding of the bed frame.
Locking System
The bed frame will be automatically locked when sliding onto either stretcher, with safety devices.
Both locking and safety devices are made of high-quality 304 stainless steel.
Guide Wheel Device
Equipped with guide wheel for easy operation and stable direction control.
Infusion Pole
Equipped with high-quality 304 stainless steel two-section adjustable infusion pole.
Brake System
Both stretchers adopt international advanced central control brake system, stable and reliable.
Casters
Brand casters, diameter 150 mm, 3-section 2-position central control.
With central lock & total lock swivel casters and precision ball bearings.
Nylon (PA6) main frame and wheel core for high load capacity.
TPU wear-resistant wheel surface, noise reduction and shock absorption, safe and reliable.
Performance
Performance and structure of the connecting stretcher reach international advanced level.
It meets the requirements of hospital operating rooms, helps prevent cross-infection, and is an ideal choice for operating rooms.
Packaging
Main stretcher: 2090*790*780 mm
Auxiliary stretcher: 1920*680*600 mm
Net weight: 135 KG
Gross weight: 180 KG
