Specifications:
| Overall dimensions: | 2160*870*620/930mm, total width of side rails: 760mm |
| Bed platform length: | 1930mm |
| Bed platform width: | 620mm |
| Height adjustment range: | 620–930mm |
| Backrest adjustment angle: | 0–75° |
| Knee rest adjustment angle: | 0–40° |
| Tilt adjustment range: | 0°–18° |
| Safe Working Load: | 300KG |
Features:
Backrest Adjustment System: Controlled by silent gas springs.
Height Adjustment System: Driven by hydraulic cylinders for more stable performance.
Bed Platform: Made of compact laminate with high strength and deformation resistance, X-ray translucent.
Frame: Constructed from high-quality steel.
Fully recessed PP rotating side-folding side rails:
Can be fixed horizontally and fully retracted under the bed surface.
Both sides of the rails are equipped with angle indicators and safety locks to improve operation safety and facilitate patient transfer to the hospital bed.
Casters: Four Ø200mm casters with central locking system. Caster control on all four corners; one-step braking locks all four wheels simultaneously.
Central Brake Linkage: Integrated round tube structure for higher strength.
Independent 5th Wheel Steering System:
Control pedals installed on both sides. Free movement when retracted; straight-line mode when activated (pedal ground clearance: 105mm for better passability). Effectively counteracts inertia during transport and ensures stable directional control for safer movement.
Integrated Oxygen Cylinder Tray: Under-bed tray for oxygen cylinder, load capacity: 10Kg.
I.V. Pole Holder: Included for convenient storage of infusion stand.
Mattress: Waterproof surface treatment, easy to clean. Equipped with zipper for removable and washable cover.
Packing:
Wooden Case Packaging
Packaging dimensions: 2310*990*860mm
Case weight: 55KG
Hydraulic stretcher weight: 132KG
Total weight: 187KG
