Specifications:
| Overall dimensions: | 1930*640*610/930mm |
| Bed platform length: | 1900mm |
| Bed platform width: | 640mm |
| Height adjustment range: | 610–930mm |
| Backrest adjustment angle: | 0–75° |
| Tilt adjustment range: | 0°–18° |
| Safe Working Load: | 300KG |
Features:
Backrest Adjustment System: Controlled by silent gas springs.
Height Adjustment System: Driven by hydraulic cylinders for more stable performance.
Bed platform and side rails: Made of imported PP engineering plastic, one-piece blow molding.
Frame: Constructed from high-quality steel.
Casters: Four Ø200mm casters with central locking system. Caster control on all four corners; one-step braking locks all four wheels simultaneously.
Central Brake Linkage: Integrated round tube structure for higher strength.
Independent 5th Wheel Steering System:
Control pedals installed on both sides. Free movement when retracted; straight-line mode when activated. Effectively counteracts inertia during transport and ensures stable directional control for safer movement.
Integrated Oxygen Cylinder Tray: Under-bed tray for oxygen cylinder, load capacity: 10Kg.
Mattress: Waterproof surface treatment, easy to clean. Equipped with zipper for removable and washable cover.
Packing:
Wooden Case Packaging
Packaging dimensions: 2010*830*720mm
Net weight: 95KG
Gross weight: 145KG
